防水光束灯 AK-B880MH-IP

Ideal for concerts, theaters, TV studios, and banquet halls, this fixture delivers high-brightness, narrow-beam dynamic lighting effects with stunning visual impact. Featuring an advanced optical system and premium LED source, it ensures reliable long-term operation—making it the top choice for professional lighting designers.

Certifications

Genuine Original
3-year warranty
CMA Certification
ISO9001 Certification
RoHS Certification
CNAS Accredited
ISO 14001 Certification
CE Certification

Model:AK-B880MH-IP

Waterproof Beam Light AK-B880MH-IP

Masterpiece Craftsmanship: Premium Design, High Power, Massive Beam. This waterproof beam light delivers top-tier performance in optics, structure, and aesthetics. Engineered with cutting-edge high-brightness light sources, advanced optical technology, and rigorous industrial design to ensure flawless lighting execution.

In Stock|Lead Time:7-15 days

Suggested Retail Price

¥8500.00/ unit

This price includes 13% VAT and shipping.

Configuration Selection

Technical Specifications

Product Name:Waterproof Beam Light AK-B880MH-IP
Product Model:AK-B880MH-IP
Input Voltage:AC100-240V
Rated Power:550W
Light Source Type:Osram
Product Color Temperature:8000K
Color Rendering Index:Ra ≥ 90
Beam Angle:2°-5°
Control Mode:DMX512/RDM
Housing Material:Aluminum
Ingress Protection Rating:IP65
Chassis Color:Black
Delivery Time:7-15 days
Factory Warranty:3 years

Product Advantages & Technical Highlights

IP65 Protection Rating

Die-cast aluminum and magnesium alloy housing with silicone O-rings and waterproof connectors withstands rain and snow, operating reliably from -30°C to 50°C.

High-brightness penetration

200W–650W cup or LED light source; delivers 15,000–40,000 lumens with strong long-distance projection and penetration.

Narrow beam angle design

2°-3° ultra-narrow beam angle paired with a precision aspheric lens array for sharp, clear beams and outstanding long-distance outdoor performance.

高速运动机构

Horizontal 540° / Vertical 270° rotation range, driven by a three-phase stepper motor for precise and rapid positioning with excellent wind resistance.

Smart Temperature Control System

Forced air cooling with real-time temperature monitoring and automatic power throttling for high-temperature protection ensures stable long-term operation.

Estimated Quantity *

Tai

Enter the estimated purchase quantity so we can provide you with a more accurate quote.

Share to social media

Product Details

1. Wide Voltage: AC90V-235V 50-60Hz
2. Wide-voltage drive power supply: 880W
3. Imported light source system: OSRAM
4. Color Temperature: 8000K
5. Color System: Palette: 14+1
6. Pattern System: Pattern Disc: 17 Fixed Pattern + 1 White Light
7. Focusing System: Electronic
8.雾化: 具有雾化功能、可实现柔光效果
9. Strobe: Dual-motor independent strobe effect, 0.5-20 flashes per second, adjustable speed.
10. Motor: The X and Y axes use three-phase motors for high stability at varying speeds and precise angular positioning!
11. Dimming Curve: 0%-100% linear dimming, smooth and flicker-free
12. Beam Angle: 2-5°
13. Dual-Channel: 16-channel or 20-channel
14. Lens Diameter: 200mm
15.防水等级:IP55
16. Control modes: DMX 512, self-run, master/slave self-run, RDM support, compatible with large-scale controllers
Controller remotely sets the address code.
17. Prism System: 16 prism and (8+16+24) prisms (prism configuration available per customer requirements).
18. Display: LCD display, adapts to different mounting positions, rotates 180°
19.水平垂直:采用高精度三相电机、定位准确、运行平滑、可自动校正定位
20. Level: 540° rotation, resolution 8/1 6-bit, with fine adjustment
21. Vertical: 270° rotation, resolution 8/1, 6-bit with fine adjustment.
22. Cooling System: Employs a physical air convection method. Software-driven thermal analysis of the luminaire enables rapid heat dissipation, extending lamp lifespan and reducing light degradation. Features a low-noise fan with superior drive performance for minimal operational noise.
23. Installation: Upright or inverted
24. Light body dimensions: 40*32*67cm
Cardboard box dimensions: 41*49*77
Net Weight: 24KG, Gross Weight: 28KG

Product specifications, images, and prices are for reference only and subject to change without notice. Please refer to the actual product.

Customer Reviews

Log in to leave a review, share your experience, and extend your warranty by 1 year(s).

Sign In
Yellow **|1***1|Yunnan **********|Wenshan, Yunnan
Certified and purchased

Malipo Border Water Park purchased over 44 B8 beam lights and more than 100 color wash, audience, and strobe lights in 3. Despite heavy thunderstorms and lightning from the beginning of 6, which damaged our outdoor LED screens, this lighting batch performed flawlessly.

Zhao **|1***3|Chengdu **** **** **|Sichuan, Chengdu
Certified and purchased

The scenic night tour project features 108 units of 880W waterproof beam lights creating stunning aerial light landmarks. With a narrow beam angle of 2°-5°, the lights deliver exceptional penetration and dramatic vertical beams at night. IP55 protection ensures stable operation in misty mountain environments, while the three-phase motor provides precise positioning without drift. A 16-facet prism adds dazzling visual effects, enhanced by haze machines to create a dreamlike night sky. RDM remote control is particularly practical for distributed lighting setups across the mountainside, significantly reducing cabling work.

Yellow **|1***5|your *** company|Guizhou

Ideal for coastal resort projects with excellent salt-spray corrosion resistance. The RDM remote control feature significantly reduces commissioning time—one console manages dozens of fixtures.

Wu*|1***9|long *** company|Hunan
Certified and purchased

Second repurchase: bought 4 units last time for testing, now ordered 12. The wide-voltage driver is very stable—our construction site has significant voltage fluctuations that often burn out other lights' power supplies, but this one has never failed. The dual-motor independent strobe effect looks amazing, and the speed adjustment range meets our needs. The three-phase motor delivers high positioning accuracy with smooth XY-axis movement and no jitter. Customer service was excellent with timely technical support responses. Shipping packaging was top-notch; each unit came in its own protective flight case. Excellent value compared to similar products on the market. Highly recommended for engineering projects.

Chen*|1***0|Mr./Ms. *** Shen|Liaoning
Certified and purchased

The beam light performs well overall, though the 24KG weight makes installation at heights challenging. The cooling system operates quietly and won't cause disturbances in a serene scenic environment.

Zhang*|1***1|***|Anhui
Certified and purchased

Performs better than expected for the theater renovation project. The focus system is precise, with fast electronic response. All 17 fixed patterns on the gobo wheel are practical. The fog effect provides soft lighting ideal for drama scenes. DMX512 integration works flawlessly and is fully compatible with our existing console. The rotatable LCD display (180°) is a thoughtful design that makes parameter checks easy during ceiling-mounted installations. Fan noise is well-controlled and won't interfere with performances. We recommend a lightweight version for smaller venues that don't require this power level.

Yang*|1***9|***|Anhui
Certified and purchased

This waterproof beam light truly lives up to its reputation. For outdoor events, our previous fixtures often failed during rain. Its IP55 rating is genuinely reliable; we used it for three consecutive days at a music festival last summer, including through two heavy downpours, with zero issues. The 880W output is powerful, delivering strong beam penetration visible even from the back rows. Osram lamps provide stable color temperature, and the color wheel switches smoothly. The only drawback is the weight, requiring a professional team for rigging. Overall, it offers excellent value and is now on our long-term procurement list.

** Liu|1***6|*** Stone|Hebei
Certified and purchased

The core device for night light shows in scenic areas, 16 prism effect covers a wide area when deployed. The LCD display can rotate 180 degrees and remains readable even when mounted upside down.

Li**|1***3|your *** company|Guizhou
Certified and purchased

The 88W light source produces a thick, powerful beam that delivers stunning night sky effects with a narrow beam angle of 2 to 5 degrees. A three-phase motor ensures precise positioning and smooth high-speed operation without vibration. With an IP55 rating, it's built for reliable outdoor use.
